Overview of the GraphWorX64 Viewer

The MobileHMI configuration for the GraphWorX64 Viewer allows the user to set up a device-specific or customized initial mobile display. It also allows the user to experiment with the compatibility of a display with specific devices in terms of the screen size and aspect ratio. It allows the user to prepare a display that is ready for deployment to a specific set of devices and platforms.

The GraphWorX64 Viewer is a human-machine interface (HMI) software package for process control that can be used to create dazzling animated graphics that can incorporate interactive HMI features, display alarms, visualize trends, replay historical data, and provide the ability to monitor assets on a map. GraphWorX64 also provides a powerful development environment where users can design HMI/SCADA control screens. It allows for the combination of 2D objects with 3D views, create shapes and smart symbols, insert controls, and add buttons and pictures.

GraphWorX64's design surface is a canvas upon which you can display real-time or historical data from any OPC, BACnet, database, SNMP, or OPC UA compliant data source in a meaningful way so that the state of your equipment, processes, conditions, or anything else you can quantify is instantly recognizable by an operator at a glance. Mobile displays based on GraphWorX64 run water treatment plants, nuclear power plants, pharmaceutical production lines, and are found in dozens of industries where automation control is necessary for the overall product or service. With the onset of new technologies, GraphWorX64 has the ability to span devices from computers to phones with Web-based WebHMI and mobile device-based MobileHMI.

Splash Screen of GraphWorX64 Devices

A GraphWorX64 display can contain other GraphWorX64 displays; TrendWorX64, AlarmWorX64 you can also incorporate3D displays and animation. A 3D display can be created by adding a 3D view to any display. 3D views can co-exist wit 2D objects and act as part of a larger display.

For newer Microsoft operating systems, ICONICS offers several multitouch-integrated features, as well.

Ribbon in GraphWorX64 of GraphWorX64 Viewer

In GraphWorX64 the user can add objects to selected display faceplates, assign properties to those objects, and associate objects with data or events. In addition to event driven dynamics the user can run scripts, generate data, give commands, and perform other actions that help increase efficiency. Just as objects can have actions associated with them, it is possible to define sequential or repetitive actions that create animation effects. For example, if a path is defined along a conveyor belt and an animation that moves a part along that belt is implemented as a function of time, then that part will appear to be moving and displaying an action. Special tools inGraphWorX64 such as Range and State dynamics offer simple ways to create animations.

Note: As the MobileHMI HTML5 app uses a different rendering engine than MobileHMI UWP and GraphWorX on the desktop, there may be some differences when it comes to supported features.

After the program fully opens, a blank workspace is visible. Begin by introducing the Ribbon and going through its options. Go to the topic Mobile Ribbon Menu to learn more about this.
